Custom Gym Wall Protection, Safety Wall Padding

Custom Safety Wall Padding is for rooms that do not fit a standard panel size. Build your order from four foam types, four mounting options, and 14 colors, then add cutouts, windows, doors, and outside corners so the padding follows your walls.

Describe your project, enter the measurements for each wall, and upload plans or photos. Our team works from what you provide to custom-fit the padding to your layout.

Why You'll Love It

• All four foam types: 100, 200, 300, and 900 Series
• Four mounting options, including Z-clip and C-channel
• Custom layouts and sizes, built like the standard panels
• Your own height, with measurements for up to four walls
• A primary color from 14 choices, plus an optional second color for an alternating pattern
• Cutouts for outlets, switches, return air registers, and thermostats
• Window cutouts and door options
• Outside corner padding, added by quantity
• Upload up to 30 plan or photo files

Choose a Padding Type

The four padding types match the standard Spark Sensory Solutions panels:

• 100 Series, a classic foam with extra softness and cushioning: 1.375" of foam, 1.875" thick with board
• 200 Series, a medium-firm foam, listed under ASTM F2440 for impact resistance: 2" of foam, 2.5" thick with board
• 300 Series, a flex-firm foam: 2.5" of foam, 3" thick with board, with added cushion compared with the 200 Series, but less shock absorption and impact resistance
• 900 Series, a Class A E-84 foam: 2" of foam, 2.5" thick with board, with a smoke developed index of 350 and a flame spread index of 25 in testing of the standard panel under ASTM E84

If a listed standard is part of your project, match it to the series that carries it.

Panel Construction

Layouts and sizes are custom, but the construction is not. Each custom panel is built the way the standard panel for your padding type is built: an OSB backing board, the foam layer for that series, and a flame retardant vinyl cover. The vinyl weight for each padding type is listed in the specifications.

Choose a Mount

Pick how the padding attaches to the wall:

• Z-clip on both the top and bottom, a fit for nearly any wall surface
• Z-clip on the top with a 1" nail margin below
• A 1" nail margin along the top and bottom, for walls of wood, drywall, concrete, or block
• C-channels along the top and bottom

Cutouts, Windows, and Doors

Need padding around wall-mounted fixtures? Panels can be cut to fit around outlets, light switches, return air registers, thermostats, and other openings, so the wall stays covered while building systems stay reachable. Give the location and size of each opening when you order.

• Access cutouts, added by quantity
• Window cutouts, added by quantity
• Door padding, with an optional door window cutout and lockset notch

Outside Corners

Where a wall turns out into the room, add outside corner padding. Corners are added by quantity, so you can match the number your layout needs.

Share Your Project

The more detail we have, the closer the layout will be to what you picture:

• A project description
• Measurements for Walls A, B, C, and D
• The height for the padding
• Up to 30 uploaded files

Where It Fits

Use custom padding wherever a wall needs protection and a standard panel will not do:

• School gyms and activity rooms
• Play areas and recreation centers
• Sensory rooms
• Hallways and rooms with doors, windows, and fixtures

eSpecial Needs offers Custom Safety Wall Padding for projects that need a custom layout.

Why We Like It

We like Custom Safety Wall Padding because you can build one order from all four foam types. Mounting options, colors, cutouts, windows, doors, and outside corners can all be set to fit your room. You can upload plans and photos so the layout follows your walls.
