- Brand
- Spark Sensory Solutions
- Series
- 900 Series - Class A E-84 Flame Retardant Medium Foam Panel
- Foam Thickness
- 2"5.1 cm
- Total Thickness with Board
- 2.5"6.4 cm
- Foam Type
- Highly flame resistant polymerized open cell foam
- Foam Density
- 6.0 to 7.0 pcf (pounds per cubic foot)
- Foam Firmness (IFD 25% Return)
- 35 to 55 lbf per 50 sq in (ASTM D3574)
- Backing
- OSB board
- Backing Thickness
- 0.4375"1.1 cm
- Cover
- 16-ounce flame retardant vinyl
- Cover Properties
- Heavy duty; resists mildew, tearing, and abrasion; UV resistant; wick resistant base fabric
- Cover Fire Rating
- ASTM E84, Class 1 or A
- Fire Test
- ASTM E84-05, Class A, tested as a single unit
- Flame Spread Index
- 25
- Smoke Developed Index
- 350
- Maximum Flame Spread (Test)
- 5.3 ft161.5 cm
- Testing Lab
- Intertek ETL SEMKO Testing Services NA, Inc., Elmendorf, TX
- Also Stated To Meet
- NFPA 255, UL 723, ANSI 2.5, UBC 8-1 (42-1) (manufacturer statement)
- Colors
- 14 colors to choose from
- Mounting Options
- Z-clip top and bottom; Z-clip top with nail margin bottom; nail margin top and bottom; C-channel top and bottom
- Z-Clip Mounting
- For mounting on nearly any wall surface
- Nail Margin Mounting
- For wood, drywall, concrete, or concrete block walls
- Nail Margin Hardware
- Not included; molding or aluminum channel to cover bolt heads is also not included
- Use
- Indoor and outdoor
- Custom Options
- Custom sizes, configurations, layouts, and printing available (contact Customer Service)
- Sold
- Priced per panel
- Origin
- Made in the USA
- Returns
- Non-returnable
